MINI ROLLS
Geotex mini rolls consists of needle-punched non-woven geotextiles, woven from 100% continuous polymer-based products. Manufactured from a variety of processes, they have been tested to meet the Australian quality standards for geotextiles. Added resilience against installation wear, strong water permeability, and inherent UV resistance.
The applications are broad ranged and based on the manufacturing process, genreally the primary function of Geotex mini rolls is often across filtration and separation and secondary functions for drainage and as a protection layer against membranes.
The products life span is to be durable for more than 25 years in soils with a pH in the range 2 to 14.
| GEOTEXTILES PROPERTIES | TEST METHOD | UNITS | TYPICAL VALUE |
| TYPICAL MASS | AS3706.1 | g/m2 | 140 |
| GRAB TENSILE | AS3706.2 | N | 410 |
| PORE SIZE | AS3706.7 | mm | 0.18 |
| FLOW RATE | AS3706.9 | l/m2/s | 270 |
| ROLL DIMENSIONS | m |
0.6 x 50 1.0 x 50 1.2 x 50 2.0 x 50 |
NOTES:
- Geotex Pty Ltd reserves the right to alter product specifications without prior notice. It is the responsibility of all users to satisfy themselves that the above data and specifications are up to date.
- Please contact Julian on 0481 333 632 if you need additional data or a specific product for your project.
